Electrical Systems

From power quality monitoring to load disaggregation to sub-metering, Enetics has the right solution for your specific measurement needs. Our proven instrument products and communications systems deliver real-time data so you can drive real-time results.


 Power Quality Monitoring Solutions

The Enetics power quality monitoring family offers a range of portable and residential (permanent) power quality tools for long term recording and analysis, preventive maintenance, and troubleshooting in residential, industrial, utility, and commercial building applications.

The Enetics power quality product family monitors and records both energy and power quality data simultaneously. Measurements include single or polyphase single-cycle rms volts, amps, watts, VARs, VA, dips/swells, harmonics, THD%, fast or sub-cycle impulses, and also record minimums, maximums, and average user programmable interval data, and flickermeter analysis per IEC 61000-4-15 specifications.

Power quality recorders are available as portable and residential (permanent)-mount units enabled with cellular modem, Bluetooth, and USB communication capability.

Designed for harsh environments, these highly accurate power quality recording instruments are packaged in IP65 rated or NEMA 4X enclosures. Even our portable units are designated for outside duty in severe weather conditions for extended periods.

Portable Three Phase Options

LM-3431 Class A Three Phase Portable Analyzer / Recorder

The LM-3431 class A three phase portable analyzer allows operators to easily address customer complaints by identifying and isolating power system problems and anomalies with confidence.

Learn More

LM-3431 Standard Three Phase Portable Analyzer / Recorder

The LM-3431 standard is an excellent solution for addressing customer complaints in regions where class A certification is not required. This portable analyzer allows operators to easily identify and isolate power system problems and anomalies with confidence.

Learn More


Residential (permanent) Options

LM-3111 Class A Dual Phase Meter Adapter Recorder

The LM-3111 class A dual phase meter adapter recorder is the perfect solution for long term residential power quality monitoring. This meter adapter recorder is installed by simply plugging into the meter base.

Learn More

LM-3111 Standard Dual Phase Meter Adapter Recorder

The LM-3111 standard may be used in regions where class A certification is not required. This is an excellent solution for long term residential power quality monitoring. This meter adapter recorder is installed by simply plugging into the meter base.

Learn More


 Load Disaggregation Solutions

Enetics brought the world’s first utility-based residential NILM (Non-Intrusive Load Monitoring) product to the marketplace in 1996 and we are recognized leaders in this technology today. Our engineering staff has been engaged in research, development and commercialization activities for non-intrusive end-use monitoring since 1993. Enetics' family of NILM products is named SPEED™ (Single Point End-use Energy Disaggregation) and employs patented disaggregation technology. This technology has been extensively deployed and tested around the world since its initial release in 1996.

The Enetics single point end-use energy disaggregation, or SPEED™ recorders, provide a breakdown of individual appliance energy consumption in addition to the total energy consumption of a residence. This information enables load research, the monitoring of demand-side management programs and addressing high utility bill complaints.

NILM is a unique approach to monitoring the energy consumption of major appliances or other loads within a home or business. With NILM technology, a single recording meter installed at the electrical service entrance captures the energy consumption and time of use for each major appliance in the home or business. Hardware installation is quick and easy and re-wiring of appliances is never required. Individual load disaggregation is accomplished using the NILMS algorithms in the Enetics’ SPEED™ software.

The Enetics SPEED™ recorders provide a breakdown of individual appliance energy consumption in addition to the total energy consumption of a residence. This information enables load research, the monitoring of demand-side management programs and addressing high utility bill complaints.

System Description

The Enetics NILM products measure the power consumption of individual loads and appliances without directly metering each of the loads. Analysis of the energy profile that flows into the residence allows the system to reveal the energy consumed by specific individual loads (appliances) within the premises. The resulting data includes total energy consumed per appliance as well as time of day "interval" data for each appliance. The product can also record and correlate temperature information with energy-use data, help to identify faulty appliances and recognize abnormal energy use.

SPEED™ System Software

Master Station:  Collects the field data, manages the recorder operations and configurations, and performs the SPEED™ algorithm disaggregation process. Recorded data at each premises is uploaded on a regular basis (typically bi-weekly) to the SPEED™ Master Station. This data resides in an SQL database for flexible access by the Analysis Station software.

Analysis Station:  Accesses data from the SQL database and presents the information to the operator in the form of graphical charts, spreadsheet tables, and summary reports. Analysis Station allows users to view appliance data over selected time periods including any subset of appliances. Additionally, Analysis Station provides for the generation of reports for the aggregation of results across multiple premises.

Field Station:  Runs on a laptop or similar PC based computer, connects directly to recorders in the field for installation verification, data collection and recorder programming and configuration updates.

Single Phase Options

LD-1120 Single Phase Meter Adapter NILM Recorder (2S base)

The LD-1120 single phase meter adapter recorder is the perfect solution for addressing customer complaints. The meter adapter recorder plugs into a residential meter base to record whole-house electrrical consumption.

Learn More

LD-1200 and LD-1201 NEMA 4S Single Phase NILM Recorder

Address customer complaints with the LD-1200 series NILM recorders. These recorders are intended to be installed at the breaker panel location in residential or commerical applications and will measure individual load profiles and recorderd energy load data.

Learn More


Three Phase Option

LD-1203 NEMA 4X Three-Phase NILM Recorder

Address customer complaints with the LD-1203 NILM recorder. This recorder is intended to be installed at the breaker panel location in residential or commerical applications and will measure individual load profiles and recorderd energy load data.

Learn More


Enetics is a New York State Certified Meter Data Service Provider (MDSP)

Enetics is New York State certified to provide end-use customers with meter data services including meter reading, billing and communications as well as load curtailment and energy management services in a web-based environment. Enetics can also obtain meter readings, provide data hosting, perform validation and convey meter data to the appropriate ESCO’s, public utilities, or private customers requesting these services.
